CHAPTER 4 Installation Requirements
4.1 Mounting Requirements
4.2 Power Supply Requirements
4.3 Connection Requirements
This chapter describes the environmental, mounting, power supply, and connection requirements.
4.1 Mounting Requirements
4.1.1 Dimensions
Figures 4.1 show the dimensions of the HDDs and the location of the mounting screw holes.
[Unit: mm]
Figure 4.1 Dimensions
C141-E266 41
