Installation Requirements
4.2 Power Supply Requirements
(1) Allowable input voltage and current
The power supply input voltage measured at the power supply connector pin of the HDDs (receiving
end) must satisfy the requirement given in Subsection 2.1.3. (For other requirements, see Items (4)
below.)
(2) Current waveform (reference)
Figure 4.6 shows the spin-up current waveform of +5V DC and +12V DC.
Time (2 sec/div) Time (2 sec/div)
Time (2 sec/div) Time (2 sec/div)
Current (500mA/div)
Current (500mA/div)
+12VDC
+5VDC
MBC2073RC
MBC2073RC MBC2036
MBC2036RC
Current (500mA/div) Current (500mA/div)
RC
Figure 4.6 Current waveform (Spin-up)
46 C141-E266
