6.5 Packaging
6.5.2 Box packaging
Cushion (upper)
Cushion (lower)
Box (multi-box)
Desicant
Unitary paked product
Seal side
Conductivity bag (large)
Figure 6.3 Box packaging
(1) Put the conductivity bag (large) into the multi-box, in addition, put the cushion (lower) into the bag.
(2) Put the bag packed products into the cushion (lower).
• Insert the seal side upward.
• In the fraction shipment, empty the slots in the Figure 6.4 where figure is larger than the number
of shipment, and fill other slots with the products.
(3) Put the desiccants between the conductivity bag (large) and the cushion (lower) in the box.
(20g x 10 area)
(4) Put the cushion (upper) into the box.
(5) Seal the conductivity bag (large) with the packaging tape.
(6) Close the box with the packaging tape. (Attach the tape in ‘H’ figure at the top.)
C141-E266 77
