Installation Requirements
4.1.2 Mounting orientations
As shown in Figure 4.2, the HDD can be installed flat on any of its six sides. Inclination from a
vertical or horizontal plane should not exceed 5°.
(a) (b)
(c) (d)
(e) (f)
Direction of gravity
Figure 4.2 HDD orientations
42 C141-E266
