Fujitsu PRIMERGY RX1330 M4 User Manual

18 Operating Manual RX1330 M4
Product description
3.1 Overview of the server
Figure 1: Server front
Pos. Component
1ODD
2ID card
3 Front panel module (not on 10x HDD/SSD version)
4
HDD/SSD:
4x 3.5-inch HDD OR
8x 2.5-inch HDD/SSD OR
4x 2.5-inch PCIe SSD and 4x 2.5-inch HDD/SSD OR
10x 2.5-inch HDD/SSD
5 Front panel on QRL (only on 10x HDD/SSD version)

Fujitsu PRIMERGY RX1330 M4 Specifications

General

Chipset	Intel C246
Processor	Intel Pentium, Intel Celeron
Memory Type	DDR4
Memory	Up to 64 GB
Memory Slots	4 DIMM slots
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
Network	2x 1GbE onboard, optional additional NICs
Power Supply	450W
Form Factor	1U
RAID Controller	optional SAS RAID controller
