Fujitsu PRIMERGY RX1330 M4 User Manual

RX1330 M4 Operating Manual 31
Product description
3.3.2.2 Indicators on the front panel
Figure 7: Indicators on the front panel module
Figure 8: Indicators on the front panel on QRL
Pos. Label Indicator Status Description
1ID
ID
indicator,
see also
"iRMC-
related
status
signals" on
page 34
blue on
The server has been highlighted
using ServerView Operations
Manager, iRMC web interface or the
ID button on the front panel for easy
identification.
flashing
blue
The server has been highlighted for
easy identification using the iRMC
with disabled local VGA output.

Fujitsu PRIMERGY RX1330 M4 Specifications

General

Chipset	Intel C246
Processor	Intel Pentium, Intel Celeron
Memory Type	DDR4
Memory	Up to 64 GB
Memory Slots	4 DIMM slots
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
Network	2x 1GbE onboard, optional additional NICs
Power Supply	450W
Form Factor	1U
RAID Controller	optional SAS RAID controller
