RX2510 M2 Operating Manual 21
Functional overview
Interfaces
Onboard or integrated controllers
Slots
USB connectors USB 2.0 connectors: 1 (1 x rear)
USB 3.0 connectors: 4 (2 x front, 2 x rear)
Graphics (15-pin) 1 x VGA
Management LAN
(RJ45)
1 x dedicated management LAN connector for
iRMC S4 (10/100/1000 Mbit/s)
RAID Controller RAID 5/6 Ctrl., HDD SAS 6 Gb, LSI, 8 ports ext.
RAID level: 0, 1, 10, 5, 50, 6, 60, 512 MB Cache,
Optional BBU (based on LSI SAS2108).
Integrated RAID 5/6 Ctrl., HDD SAS 6 Gb, Fujitsu, 8
ports int. RAID level: 0, 1, 10, 5, 50, 6, 60, 1024 MB
Cache, Optional FBU (based on LSI SAS2208).
Integrated RAID 5/6 Ctrl., HDD SAS 6 Gb, Fujitsu, 8
ports int. RAID level: 0, 1, 10, 5, 50, 6, 60, 512 MB
Cache, Optional BBU (based on LSI SAS2108).
Integrated RAID 0/1 Ctrl., SAS/SATA 6 Gb, Fujitsu, 8
ports int. RAID level: 0, 1, 10, No BBU support
(based on LSI SAS2008).
SATA Controller Intel
®
C612, 1 x SATA channel for ODD
Remote Management
Controller
Integrated Remote Management Controller
(iRMC S4), 256MB DDR3-800 SRAM for video, IPMI
2.0 compatible
PCI-Express 3.0 x8 2 x low profile
PCI-Express 3.0 x16 2x low profile (2nd processor required for slot 4)
Slot notes One PCIe Gen3 x8 slot may be occupied with a
Modular RAID controller if configured.
