22 Operating Manual RX2510 M2
Drive bays
Operating Panel
Dimensions / Weight
Hard disk bay
configuration
4x 2.5-inch (with 3.5-inch installation frame) or 4 x
3.5-inch
Operating buttons On/off button
Reset button
NMI button
ID button
Status LEDs Global error indicator (orange)
ID indicator (blue)
Power-on indicator (green)
CSS indicator (orange)
Status LEDs at system
rear side
Global error / CSS / ID indicator (orange / orange /
blue)
LAN connection indicator (green)
LAN speed indicator (green / yellow)
Rack (W x D x H) 482.6 mm (bezel) / 435.4 mm (body) x 770.7 mm x
42.85 mm
Mounting depth rack 748.2 mm
Height unit rack 1 U
19" rack mount yes
Mounting cable depth
rack
200 mm (1000 mm rack recommended)
Weight 8.8.kg - 16.0 kg
Weight notes actual weight may vary depending on configuration
Rack mounting kit 3.5 kg
