RX2510 M2 Operating Manual 55
Starting up and operation
6.1.2 Rear of the server
CSS, Global Error and ID indicators
Figure 8: Global Error / CSS / ID indicator
1 Global Error / CSS / ID indicator
Symbol Indicator Status Description
Global Error
indicator
off no critical event (non CSS component)
orange on
prefailure detected (non CSS
component)
orange
flashing
non CSS component failure
[CSS]
CSS
indicator
off no critical event (CSS component)
orange on prefailure detected (CSS component)
orange
flashing
CSS component failure
ID ID indicator
blue on
server has been highlighted using
ServerView Operations Manager,
iRMC web frontend or the ID button on
the front panel for easy identification
blue
flashing
server has been highlighted using
IRMC (AVR) when local VGA off for
easy identification
!
