22 Operating Manual RX4770 M4
© cognitas. Gesellschft für Technik-Dokumentation mbH 2017 Pfad: W:\AppData\Local\FCT\tim_local\work\PICHOL\OBJ_DOKU-31714-001.fm
2.2 Server specification
This section explains the specifications for the server. The specifications for this
server are liable to be updated without any notice. Please be forewarned.
System Board
Processor
Memory Modules Configuration
System board type D3753
Chipset Intel
®
C624 Chipset
Processor quantity and
type
2 or 4 Intel
®
Xeon
®
CPUs (Platinum, Gold)
Processor notes A minimum of 2 CPUs or maximum of 4 CPUs must
be configured, no mix of different CPU types
Memory slots 48 (12 DIMMs per CPU, 6 channels with 2 slots per
channel)
Memory slot type DIMM (DDR4)
Memory capacity
(min. - max.)
16 GB - 6144 GB
Memory protection Advanced ECC, Memory scrubbing, SDDC, Memory
mirroring support, Rank sparing memory support
Memory notes Memory modules with 8, 16, 32, 64 or 128 GB and
2666 MHz are available.
