RX4770 M4 Operating Manual 23
Interfaces
Onboard or integrated controllers
USB connectors 5 x USB 3.0 (2x front, 2x rear, 1 internal)
Graphics (15-pin) 2 x VGA (1x front, 1x rear)
Serial (9-pin) 1 x serial RS-232-C
LAN / Ethernet OCP option:
– 4x 1 Gb
– 2x 10 Gb
– 2x 10 Gb SFP+
– 4x 10 Gb SFP+
Management LAN
(RJ45)
1 x dedicated service LAN port for iRMC S5
(10/100/1000 Mbit/s). Service LAN traffic can be
switched to shared onboard Gbit LAN port.
RAID controller Modular Host Bus Adapter with "Integrated RAID" (IR)
RAID levels 0 and 1 are supported for internal HDD
configurations.
SATA controller Intel
®
C624, 1x SATA channel for ODD
LAN controller (optional) OCP based on Emulex XE100 series;
PXE-Boot via LAN from PXE server,
iSCSI / FCoE boot (also diskless)
Remote Management
Controller
Integrated Remote Management Controller (iRMC S5)
with 256 MB DDR3-800 SRAM for video, IPMI 2.0
compatible
Trusted Platform Module
(TPM)
Infineon / TPM 1.2 or TPM 2.0 module; TCG compliant
(option)
RAID controllers Modular RAID 0/1 controller with "MegaRAID" levels 0,
1, 10, 5, 50, 6 and 60 are supported for internal HDD
configurations. As an option, a flash backup unit (FBU)
can save the memory content even if the power fails.
Cache memory size of 1 GB or 2 GB are available.
Modular RAID 5/6
controller with
"MegaRAID
functionality" (integrated
MegaRAID).
RAID levels 0, 1, 10, 5, 50, 6 and 60 are supported for
internal HDD configurations. As an option, a flash
backup unit (FBU) can save the memory content even if
the power fails. Cache memory size of 1GB or 2GB are
available.
