RX4770 M4 Operating Manual 57
Starting up and operation
6.1.1.2 Indicators on the control panel
Figure 8: Indicators on the front panel
Pos. Label Indicator Status Description
1 ID
ID
indicator,
see also
"iRMC-
related
status
signals" on
page 59
blue on
The server has been highlighted
using ServerView Operations
Manager, iRMC web frontend or
the ID button on the front panel for
easy identification.
blue
flashing
The server has been highlighted
for easy identification using the
iRMC (AVR) with disabled local
VGA output.
2 [CSS]
CSS
indicator
off
No critical event detected (CSS
component).
orange
on
Prefailure event detected (CSS
component).
orange
flashing
CSS component failure detected.
