6.1.1.3 Indicators on the accessible drives / components
Indicator on the ODD
Figure 9: Indicator on the ODD
I There are also ODDs without activity indicators.
Pos. Indicator Status Description
1
Activity
indicator
off The ODD is inactive.
green on The storage medium is being accessed.
