68 Operating Manual RX4770 M4
Starting up and operation
© cognitas. Gesellschft für Technik-Dokumentation mbH 2017 Pfad: W:\AppData\Local\FCT\tim_local\work\PICHOL\OBJ_DOKU-31718-001.fm
6.3 Switching the server on and off
V CAUTION!
● If nothing appears on the screen but flickering stripes after switching
on the server, switch the server off immediately (see chapter
"Troubleshooting and tips" on page 77).
● The On/Off button does not disconnect the server from the mains
voltage. To completely disconnect it from the mains voltage, remove
the power plug(s) from the socket(s).
● Do not move, strike, or shake the server when it is turned on. This can
damage the hard disk in the server and cause data loss.
● Turn the server on when the temperature is in its operating
environment range (10 - 35°C
1
resp. 10 - 40°C). For details on the
operating environment, refer to section "Server specification" on
page 26. When operating the device outside of this operating
environment, the server may operate improperly, damage data etc.
Furthermore, Fujitsu cannot be held responsible for any related
damage, malfunction, or loss of data, etc.
● Be sure to wait for 10 seconds or more after shutdown before turning
the server on.
● After connecting the power cords, press the On/Off button after it
passes for more than 10 seconds.
Switching the server on
The AC indicator (see figure 13 on page 65) lights up green (standby mode)
when the server is connected to the mains.
The controls and indicators are shown in figure 7 on page 55 and figure 8 on
page 57.
I It takes about 60 seconds until power-on becomes possible.
1
only for processors with a TDP from >165 W to 205 W
