Slots
Drive bays
General system information
Operating Panel
PCI-Express Gen3 x16 4 x low profile
4 x full height
Slot notes One PCIe Gen3 x16 on slot #8 may be used for the
internal modular RAID controller with FBU option, if
selected.
HDD/SSD bay
configuration
16 x 2.5-inch SAS/SATA HDD/SSD
(
Installed CPUs <= 165 W)
(In case of the above configuration, it is also possible
to install up to 12 x PCIe SSD).
8 x 2.5-inch SAS/SATA HDD/SSD/PCIe SSD
(
Installed CPUs > 165 W)
(In case of the above configuration, it is also possible
to install up to 8 x PCIe SSD).
Accessible drive bays 1 x 5.25 / 0.5-inch for DVD / RW Blu-ray
Notes accessible drives All possible options described in relevant system
configurator
System Fan 12 x (supports one rotor fail)
Fan configuration hot-plug
Operating buttons On/off button
NMI button
Reset button
ID button
