RX4770 M4 Operating Manual 25
Functional overview
Dimensions / Weight
Status LEDs
Global error indicator (orange)
CSS indicator (orange)
ID Indicator (blue)
HDD/SSD activity indicator (green)
Power-on indicator (green)
AC connected indicator (green)
At system rear side:
Global error indicator (orange)
CSS indicator (orange)
ID Indicator (blue)
AC connected indicator (green)
LAN connection indicator (green)
LAN speed indicator (green / yellow)
Rack (W x D x H) 482.6 mm (Bezel) / 434.8 mm (Body) x 724.8 mm x
86.9 mm
Mounting Depth Rack 741.3 mm
Height Unit Rack 2 U
19-inch rackmount Yes
Mounting cable depth
rack
200 mm (1000 mm rack recommended)
Weight 22.2 kg – 29.5 kg
Weight notes Actual weight may vary depending on configuration
Rack integration kit Rack integration kit as option
