TX100 S2 Operating Manual 15
Preface
1.4 Notational conventions
The following notational conventions are used in this manual:
1.5 Technical data
Electrical data
Text in italics indicates commands or menu items.
"Quotation marks" indicate names of chapters and terms that are being
emphasized.
Ê describes activities that must be performed in the order
shown.
V CAUTION! pay particular attention to texts marked with this symbol.
Failure to observe this warning may endanger your life,
destroy the system or lead to the loss of data.
I indicates additional information, notes and tips.
Rated voltage range 100 V - 240 V
Frequency 50 Hz - 60 Hz
Rated current with basic
configuration
100 V - 240 V / 0.7 A - 0.3 A
Max. rated current 100 V - 240 V / 6.0 A - 3.0 A
AC outlet 100 V - 240 V / 3.0 A - 1.5 A
Effective power 26 W - 171 W
Apparent power 31 VA - 171 VA
Heat dissipation 94 kJ/h - 616 kJ/h (89 btu/h - 583 btu/h)
Main power fuse 16 A
Protection class I
