TX100 S2 Operating Manual 47
Installation and operation
5.1.2 Rear of server
Push button mains switch
Figure 5: Push button mains switch (1)
A 0-Watt device consumes no current in two cases:
– It is switched off.
– It is in quiescent state.
The 0-Watt device is equipped with a push button mains switch which can be
used if the 0-Watt device can no longer be started, for instance because the
lithium battery is discharged.
After the push button mains switch has been pressed for a short time, the server
can be switched on again using the On/Off button at the front of the server.
/
