TX100 S2 Operating Manual 31
Important notes
3.4 ENERGY STAR
The system has a hibernate mode (S4 mode) from which it can be woken up via
WOL (Wake-up On LAN). In order to use this feature, however, the S4 mode
must be activated/enabled in the corresponding operating system installed.
The following description is an example and can only serve as a guide for other
operating systems.
To bring your system into S4 mode (= hibernate mode), proceed as follows:
BIOS Setup
Ê In the Power menu of the BIOS setup, set the 0-Watt PC Feature parameter to
Disabled.
Operating system Microsoft Windows 2008 Enterprise Edition
Activation
Ê Open a DOS shell using C:\Windows\System32\cmd.exe and enter the
following command to activate S4 mode:
In typical configurations the PRIMERGY TX100 S2 satisfies the
stringent requirements of the Ecolabel Energy Star for
Computers Version 5.0. These requirements ensure energy
savings when computers are being used and performing a range
of tasks, as well as when they are turned off or into a low power
mode. For example, the power consumption of the PRIMERGY
TX100 S2 in the operation mode “idle” is less than 65 W.
Products that have been certified compliant with ENERGY STAR
and identified as such are in full compliance with the specification
at shipping. Note that energy consumption can be affected by
software that is installed or any changes that are made to the
BIOS or energy options subsequently. In such cases, the
properties guaranteed by ENERGY STAR can no longer be
assured.
The "ServerView Operations Manager" user guide contains
instructions for reading out measurement values, including those
relating to current energy consumption and air temperatures.
Either the Performance Monitor or the Task Manager can be used
to read out CPU utilization levels.

Fujitsu PRIMERGY TX100 S2 Specifications

General

Tcase	72.7 °C
Bus type	DMI
Stepping	B1
FSB Parity	No
Processor code	SLBLJ
Processor cache	8 MB
Processor cores	4
Processor model	X3430
System bus rate	2.5 GT/s
Processor series	Intel Xeon 3400 Series
Processor socket	LGA 1156 (Socket H)
Processor codename	Lynnfield
Motherboard chipset	Intel® 3420
Processing Die size	296 mm²
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	- MHz
Processor boost frequency	2.8 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x16, 2x8, 4x4
Supported instruction sets	SSE4.2
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	18
Physical Address Extension (PAE)	36 bit
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3-SDRAM
Number of Processing Die Transistors	774 M
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	800, 1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
HDD size	3.5 \
HDD interface	Serial ATA
Optical drive type	DVD-RW
Total storage capacity	1000 GB
Maximum storage capacity	4 TB
Number of HDDs installed	2
Memory slots	4x DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Maximum internal memory	16 GB
Memory layout (slots x size)	2 x 2 GB
Maximum graphics card memory	64 MB
Graphics card	ES1000
LAN controller	Intel® 82578DM
Networking features	Gigabyte Ethernet
PS/2 ports quantity	0
USB 2.0 ports quantity	11
PCI Express slots version	2.0
Power supply	250 W
Power requirements	100 - 127 V, 200 - 240 V, 47 - 63 Hz
Power consumption (typical)	171 W
Noise level	24 dB
Operating system installed	-
Compatible operating systems	Windows Server 2008, Server 2003 Novell SUSE Linux Enterprise Server Red Hat Enterprise Linux
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	10 - 85 %
Sustainability certificates	ENERGY STAR
Certification	GS CE CSAc/us ULc/us FCC CB RoHS WEEE
Chassis type	Tower
Processor ARK ID	42927
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	386 mm
Width	203 mm
Height	390 mm
Weight	12000 g
