40 Operating Manual T X100 S2
Installing the hardware
4.3 Connecting devices to the server
Most of the ports for external devices are on the rear of the server. The
additional ports available on your server depend on the expansion cards
installed. The standard ports (figure 2) are marked with symbols, and some are
color-coded.
Figure 2: Connection panel on the rear
1 Serial port COM1 3 6 x USB port
2 Monitor port (VGA) 4 LAN port 1
/
0
1
2
