Fujitsu PRIMERGY TX100 S2 User Manual

Operating Manual T X100 S2
Contents
5.1 Control and display elements . . . . . . . . . . . . . . . . . . 45
5.1.1 Front of server . . . . . . . . . . . . . . . . . . . . . . . . . . 45
5.1.1.1 Control elements . . . . . . . . . . . . . . . . . . . . . . . 46
5.1.1.2 Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
5.1.2 Rear of server . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
5.2 Switching the server on and off . . . . . . . . . . . . . . . . 49
5.3 Configuring the server . . . . . . . . . . . . . . . . . . . . . 51
5.3.1 Configuring the onboard SATA controller . . . . . . . . . . . . . 51
5.3.2 Configuring the server and installing the operating system with the
ServerView Installation Manager . . . . . . . . . . . . . . . . . 52
5.3.3 Configuring the server and installing the operating system without the
ServerView Installation Manager . . . . . . . . . . . . . . . . . 53
5.4 Cleaning the server . . . . . . . . . . . . . . . . . . . . . . . 53
6 Property and data protection . . . . . . . . . . . . . . . . . . 55
6.1 BIOS Setup security functions . . . . . . . . . . . . . . . . . 55
7 Troubleshooting and tips . . . . . . . . . . . . . . . . . . . . 57
7.1 Power-on indicator remains unlit . . . . . . . . . . . . . . . . 57
7.2 Server switches off itself . . . . . . . . . . . . . . . . . . . . 58
7.3 Screen remains blank . . . . . . . . . . . . . . . . . . . . . . 58
7.4 Flickering stripes on monitor screen . . . . . . . . . . . . . 59
7.5 No screen display or display drifts . . . . . . . . . . . . . . . 59
7.6 Incorrect date and time . . . . . . . . . . . . . . . . . . . . . 60
7.7 Hard disk drive error messages at system boot . . . . . . . . 60
7.8 Added drive reported as defective . . . . . . . . . . . . . . . 61
7.9 Error message on screen . . . . . . . . . . . . . . . . . . . . 61
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Fujitsu PRIMERGY TX100 S2 Specifications

General

Tcase	72.7 °C
Bus type	DMI
Stepping	B1
FSB Parity	No
Processor code	SLBLJ
Processor cache	8 MB
Processor cores	4
Processor model	X3430
System bus rate	2.5 GT/s
Processor series	Intel Xeon 3400 Series
Processor socket	LGA 1156 (Socket H)
Processor codename	Lynnfield
Motherboard chipset	Intel® 3420
Processing Die size	296 mm²
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	- MHz
Processor boost frequency	2.8 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x16, 2x8, 4x4
Supported instruction sets	SSE4.2
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	18
Physical Address Extension (PAE)	36 bit
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3-SDRAM
Number of Processing Die Transistors	774 M
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	800, 1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
HDD size	3.5 \
HDD interface	Serial ATA
Optical drive type	DVD-RW
Total storage capacity	1000 GB
Maximum storage capacity	4 TB
Number of HDDs installed	2
Memory slots	4x DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Maximum internal memory	16 GB
Memory layout (slots x size)	2 x 2 GB
Maximum graphics card memory	64 MB
Graphics card	ES1000
LAN controller	Intel® 82578DM
Networking features	Gigabyte Ethernet
PS/2 ports quantity	0
USB 2.0 ports quantity	11
PCI Express slots version	2.0
Power supply	250 W
Power requirements	100 - 127 V, 200 - 240 V, 47 - 63 Hz
Power consumption (typical)	171 W
Noise level	24 dB
Operating system installed	-
Compatible operating systems	Windows Server 2008, Server 2003 Novell SUSE Linux Enterprise Server Red Hat Enterprise Linux
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	10 - 85 %
Sustainability certificates	ENERGY STAR
Certification	GS CE CSAc/us ULc/us FCC CB RoHS WEEE
Chassis type	Tower
Processor ARK ID	42927
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	386 mm
Width	203 mm
Height	390 mm
Weight	12000 g
