Fujitsu PRIMERGY TX1330 M3 User Manual

54 Operating Manual TX1330 M3
Hardware installation
5.5.1 Using cable ties (standard PSU)
You can secure the power cable using a cable tie to ensure that the insulated
connector cannot be disconnected from the server accidentally. The cable tie is
included in the accessories pack that is delivered together with the server.
Figure 3: Using cable ties (standard PSU)
Ê Thread the cable tie through the eye (1).
Ê Pull the cable tie tight to secure the power cable.
The insulated connector cannot now be disconnected from the server
accidentally.
You can loosen the cable tie by opening the small locking lever (2).
햲
햳

Fujitsu PRIMERGY TX1330 M3 Specifications

General

Processor socket	-
Built-in processor	No
Motherboard chipset	Intel® C236
Compatible processor series	Intel Core i3, Intel Pentium Dual-Core, Intel Xeon
Number of processors supported	1
ECC	Yes
Number of DIMM slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Storage drive sizes supported	2.5, 3.5 \
Supported storage drive types	HDD & SSD
Number of storage drives supported	24
Supported storage drive interfaces	Serial ATA, Serial Attached SCSI (SAS)
LAN controller	Intel I210
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	2
PCI Express slots version	3.0
Chassis type	Rack (4U)
Product color	Black, Red
