Fujitsu PRIMERGY TX1330 M3 User Manual

TX1330 M3 Operating Manual 63
Starting up and operation
6.2.1.1 Control elements
Lock (only floorstand model)
The server can be locked to prevent access to the drives.
Pos. Label Button Function
1 RESET Reset button
Reboots the system.
Press the reset button with a straightened end
of a paper clip.
V CAUTION!
Risk of data loss!
2 NMI NMI button
Used to troubleshoot software and device driver
errors.
Press the NMI button with a straightened end of
a paper clip.
V CAUTION!
Use this button only if directed to do so
by qualified certified maintenance
personnel!
3 ID ID button
Highlights the ID indicator on the front panel and
the rear panel for easy server identification.
4 On/Off button
Used to switch the server on or off.
I If the system is running an ACPI-
compliant operating system, pressing
the On/Off button will perform a graceful
shutdown.

Fujitsu PRIMERGY TX1330 M3 Specifications

General

Processor socket	-
Built-in processor	No
Motherboard chipset	Intel® C236
Compatible processor series	Intel Core i3, Intel Pentium Dual-Core, Intel Xeon
Number of processors supported	1
ECC	Yes
Number of DIMM slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Storage drive sizes supported	2.5, 3.5 \
Supported storage drive types	HDD & SSD
Number of storage drives supported	24
Supported storage drive interfaces	Serial ATA, Serial Attached SCSI (SAS)
LAN controller	Intel I210
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	2
PCI Express slots version	3.0
Chassis type	Rack (4U)
Product color	Black, Red
