64 Operating Manual
TX1330 M3
Starting up and operation
6.2.1.2 Indicators on the control panel
Pos. Label Indicator Status Description
1 ID
ID indicator,
see also
"iRMC-
related
status
signals" on
page 65
blue on
The server has been highlighted
using ServerView Operations
Manager, iRMC web frontend or the
ID button on the front panel for easy
identification.
blue
flashing
The server has been highlighted for
easy identification using the iRMC
(AVR) with disabled local VGA
output.
2 [CSS]
CSS
indicator
off
No critical event detected (CSS
component).
orange on
Prefailure event detected (CSS
component).
orange
flashing
CSS component failure detected.
3
Global Error
indicator,
see also
"iRMC-
related
status
signals" on
page 65
off
No critical event detected (non CSS
component).
orange on
Prefailure event detected (non CSS
component).
orange
flashing
Non CSS component failure
detected.
Possible causes:
– System is out of the temperature
specified range
– Defective sensor
– CPU error
– Error detected by server
management software
4
HDD/SSD
activity
indicator
green
flashing
Data access in progress.
!
