Fujitsu PRIMERGY TX1330 M3 User Manual

TX1330 M3 Operating Manual 65
Starting up and operation
iRMC-related status signals
5
Power-on
indicator
off The server is switched off.
green on
– The server has been switched on
but Power Cycle Delay settings
delay it from turning on for a
specified time.
– The server is switched on and
operating normally.
green
flashing
slowly
The BMC firmware is starting up
after the server has been connected
to the mains.
6
AC
connected
indicator
green on
– The server is switched off and
connected to the mains
(standby mode).
– The server has been switched on
but Power Cycle Delay settings
delay it from turning on for a
specified time.
I After connecting the server to
the mains, it will take about
60 seconds until the server
will enter standby mode and
can be switched on.
off
– The server is switched off and
not connected to the mains.
– The server is switched on and
operating normally.
ID indicator
Global error
indicator
Description
blue flashing off
A remote connection has been
established. Local VGA output has been
disabled during the remote session.
Pos. Label Indicator Status Description

Fujitsu PRIMERGY TX1330 M3 Specifications

General

Processor socket	-
Built-in processor	No
Motherboard chipset	Intel® C236
Compatible processor series	Intel Core i3, Intel Pentium Dual-Core, Intel Xeon
Number of processors supported	1
ECC	Yes
Number of DIMM slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Storage drive sizes supported	2.5, 3.5 \
Supported storage drive types	HDD & SSD
Number of storage drives supported	24
Supported storage drive interfaces	Serial ATA, Serial Attached SCSI (SAS)
LAN controller	Intel I210
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	2
PCI Express slots version	3.0
Chassis type	Rack (4U)
Product color	Black, Red
