Fujitsu PRIMERGY TX1330 M4

TX1330 M4 Operating Manual 39
Product description
LAN indicators
Figure 12: LAN indicators
Pos. Indicator Status Description
1
LAN
link/transfer
indicator
green on
A LAN connection has been
established.
off LAN is not connected.
flashing
green
LAN data transfer is in progress.
2
LAN speed
indicator
yellow on Data traffic at a transfer rate of 1 Gbit/s.
green on
Data traffic at a transfer rate of
100 Mbit/s.
off
Data traffic at a transfer rate of
10 Mbit/s.
햲 햳
햲 햳 햲 햳
