Fujitsu PRIMERGY TX150 S8 System Configurator And Order-Information Guide

System configurator and order-information guide
PRIMERGY TX150 S8 Status 2016-02-29
D1
S26361-F3694-E10 Independent Mode
Independent Channel Mode allows all channels to be populated in any order. No specific Memory RAS features are defined
Requires min 1 memory Module per CPU
S26361-F3695-E1 Rank Sparing Mode Installation
BIOS Setup factory preinstalled to this mode. One Rank is spare of other ranks on the same channel. Spare Rank is not shown in System Memory.
For effective capacity within a channel, please have a look below.
Supported for RDIMM only.
1x Requires min 2x 1R/2R or 1x 4R modules per CPU
S26361-F3695-E2 Performance Mode Installation
BIOS Setup factory preinstalled for max. Performance, LV memory might be set to 1.5V operation. Four identical memory modules
will be equipped in one memory bank to achieve highest memory performance. All four modules are active and full capacity can be used.
Multiple of 3 identical modules to be configured
S26361-F3695-E3 Mirrored Channel Mode Installation
BIOS Setup factory preinstalled to this mode. 2 identical memory modules are always equipped in one memory bank to use the
Mirrored channel Mode. Only one module contains active data, the 2nd module contains mirrored data
Supported for RDIMM only.
2 identical modules to be configured
1R
2R
1R
2R
na na na na na
na na
Minimum one memory module or order code = first memory
Note 1.)
Unbuffered Memory (UDIMM) no SDDC (chipkill) support
Max. DDR3 memory speed depends on the memory configuration
- one DDR3 unbuffered ECC mem. Module, 1.35V
(No of mem modules per channe) as well as on the CPU type.
Choose up to 6 order codes per CPU
The memory channel with the lowest speed defines the speed
6x per of all CPU channels in the system.
CPU, max. 2GB (1x2GB) 1Rx8 L DDR3-1600 U ECC S26361-F3694-E513 For real memory speed (depending on memory type / population),
2 modules
4GB (1x4GB) 2Rx8 L DDR3-1600 U ECC S26361-F3694-E514 please check the spreadsheet "Memory speed" below
per channel Registered Memory (RDIMM) with SDDC (chipkill) support
- one DDR3 registered ECC mem. Module, 1.35V
1600MHz supported with up to 2DPC (8 modules/CPU)
at 1.5V Mix of memory modules is only possible within the same group
Choose up to 6 order codes per CPU
4GB (1x4GB) 1Rx4 L DDR3-1600 R ECC S26361-F3697-E514
8GB (1x8GB) 2Rx4 L DDR3-1600 R ECC S26361-F3697-E515
16GB (1x16GB) 2Rx4 L DDR3-1600 R ECC S26361-F3697-E516
1DPC
2DPC
4GB
12GB
24GB
Effective Memory capacity / Rank Sparing Mode, 1 Channel populated
UDIMM
RDIMM
2GB
2GB
4GB
8GB
2R
16GB
H
Fujitsu PRIMERGY Server 10 of 24
