System configurator and order-information guide
PRIMERGY TX150 S8 Status 2016-02-29
1x mandatory for redundant base units
S26113-F575-E10 For redundant Base Units only
2x Power supply 450W
(V201, V401, V601 and V801)
occupies one bay for For redundant floorstand versions only
hot plug power supply
A second, redundant power supply requires an additional
country specific power cord (section XIII)
For later upgrades the following kits are available:
1 power supply module 450W hot plug:
Attention: There is no power cable included!
Std to Redundant Upgrade Kit S26361-F3699-L1
consisting of a redundant PSU cage and backplane
AND a 4th fan for fan redundancy
Does not contain any PSU module
II
Processor
There is1 processor socket available.
Max.1 CPU can be selected per basic unit
Note: Max. DDR3 Bus Speed depends on:
One of following CPU´s has to be selected - max. DDR3 Bus Speed from the CPU and
for an orderable basic unit
- max. DDR3 Memory Speed and
Basic 4C Pentium - max. memory modules on one memory channel
- 1x 64-bit Intel Pentium (5MB shared TLC = Third Level Cache )
1066 MHz DDR3 Bus, 6,40 GT/s QPI Bus and passive heat sink
occupies CPU socket
Pentium 1403 2C/2T 2.60GHz 5MB 6.40GT/s 1066MHz 80W S26361-F3726-E260
Basic 4C Single Socket Xeon
- 1x 64-bit Intel Xeon (10MB shared TLC = Third Level Cache )
1333 MHz DDR3 Bus, 6,40 GT/s QPI Bus and passive heat sink
Xeon E5-1410 4C/8T 2.80GHz 10MB 6.40GT/s 1333MHz 80W S26361-F3751-E280
Basic 4C CPU's
- 1x 64-bit Intel Xeon (10MB shared TLC = Third Level Cache )
1066 MHz DDR3 Bus, 6,40 GT/s QPI Bus and passive heat sink
occupies CPU socket
Xeon E5-2403 4C/4T 1.80GHz 10MB 6.40GT/s 1066MHz 80W S26361-F3684-E180
Xeon E5-2407 4C/4T 2.20GHz 10MB 6.40GT/s 1066MHz 80W S26361-F3684-E220
- 1x 64-bit Intel Xeon (15MB shared TLC = Third Level Cache ); Hyper-Threading (HT);
1333 MHz DDR3 Bus, 7,20 GT/s QPI Bus and passive heat sink
occupies CPU socket
Xeon E5-2420 6C/12T 1.90GHz 15MB 7.20GT/s 1333MHz 95W S26361-F3723-E190
Xeon E5-2430 6C/12T 2.20GHz 15MB 7.20GT/s 1333MHz 95W S26361-F3723-E220
Xeon E5-2440 6C/12T 2.40GHz 15MB 7.20GT/s 1333MHz 95W S26361-F3723-E240
- 1x 64-bit Intel Xeon (20MB shared TLC = Third Level Cache ); Hyper-Threading (HT);
1600 MHz DDR3 Bus, 8,00 GT/s QPI Bus and passive heat sink
occupies CPU socket
Xeon E5-2450 8C/16T 2.10GHz 20MB 8.00GT/s 1600MHz 95W S26361-F3724-E210
- 1x 64-bit Intel Xeon (15MB shared TLC = Third Level Cache ); Hyper-Threading (HT);
1333 MHz DDR3 Bus, 7,20 GT/s QPI Bus and passive heat sink
occupies CPU socket
Xeon E5-2430L 6C/12T 2.00GHz 15MB 7.20GT/s 1333MHz 60W
Fujitsu PRIMERGY Server 8 of 24
