Fujitsu PRIMERGY TX150 S8 System Configurator And Order-Information Guide

System configurator and order-information guide
I
PRIMERGY TX150 S8 Status 2016-02-29
as soon as available
S26361-F3749-E1
The adapter is also available as optional (loose) delivery
USB3.0 PCIe x1 adapter card
with FH and LP bracket included
Sunrich U-720
S26361-F3749-L501
PCIe x1
1 port intern, 1 port extern
USB 3.0 A jacks
max. 1x per system
as soon as available
S26361-F3750-E4 RDX cartridges must be ordered separately
RDX Drive USB3.0 5.25" internal RDX 320GB = S26361-F3857-L320
100MB/s, USB 3.0 RDX 500GB = S26361-F3857-L500
Connector: USB 3.0 "B"
RDX 1TB = S26361-F3857-L600
with USB cable
10x RDX320 = S26361-F3857-L329
without RDX cartridges
1.6 * 5.25", black bezel
max. 1x per system
S26361-F3750-E324 S26361-F3750-E504 S26361-F3750-E604
RDX 320 5.25"
RDX 500 5.25" RDX 1000 5.25"
100MB/s, USB 3.0 100MB/s, USB 3.0 100MB/s, USB 3.0
Connector: USB 3.0 "B" Connector: USB 3.0 "B"
Connector: USB 3.0 "B"
with USB3.0 cable with USB3.0 cable with USB3.0 cable
with 320GB RDX cartridge with 500GB RDX cartridge
with 1TB RDX cartridge
1.6 * 5.25", black bezel 1.6 * 5.25", black bezel 1.6 * 5.25", black bezel
max. 1x per system
max. 1x per system
max. 1x per system
SAS Controller for internal Backup Drives
S26361-F3674-E1
For internal SAS Backup drives
Onboard 4 port SAS Controller
the onboard 4-port SAS controller "Patsburg B" has to be configured
LSI
Patsburg B is not available for SLES10!
Patsburg B
1x
RAID 0, 1 & 10
RDX cartridges must be ordered separately
no controller cache
RDX 320GB = S26361-F3857-L320
SAS 6Gb/sec
RDX 500GB = S26361-F3857-L500
4 internal ports
RDX 1TB = S26361-F3857-L600
PCIe x4 10x RDX320 = S26361-F3857-L329
no PCI slot required
max. 1x per system
S26361-F3561-E4 S26361-F3626-E2 S26361-F3627-E1 S26361-F3787-E1
Tape drive LTO3HH Ultrium SAS Tape drive LTO4 HH SAS IBM V2
Tape drive LTO5HH Ultrium SAS
Tape drive LTO6HH Ultrium SAS
400GB, 60MB/s, SAS 3Gb 800GB, 120MB/s, SAS 6Gb 1500GB, 140MB/s, SAS 6Gb 2500GB, 160MB/s, SAS 6Gb
1x Connector: mini-SAS Connector: mini-SAS Connector: mini-SAS Connector: mini-SAS
incl. SAS cable
incl. SAS cable
incl. SAS cable incl. SAS cable
incl. cleaning cartridge incl. cleaning cartridge incl. cleaning cartridge incl. cleaning cartridge
without data cartridge without data cartridge
without data cartridge
without data cartridge
1.6 * 5.25", black bezel
1.6 * 5.25"
1.6 * 5.25"
1.6 * 5.25"
max. 1x per system
max. 1x per system
max. 1x per system
max. 1x per system
J
USB 3.0 adapter and RDX USB3.0 drive
LTFS (Linear Tape
File System) is not
supported
Fujitsu PRIMERGY Server 14 of 24
