System configurator and order-information guide
PRIMERGY TX150 S8 Status 2016-02-29
J
Section
SAS RAID Controller for up to 4 SAS HDDs
S26361-F3674-E1
Onboard 4 port SAS Controller
If the onboard 4 port SATA or SAS Controller is used for HDD,
it is not possible to implement a LTO drive later
Patsburg B replaces 4 onb. SATA ports
no controller cache
SAS 6Gb/sec
4 internal ports
PCIe x4
no PCI slot required
max. 1x per system
3.5" HDDs for LFF base units; SAS or more than 4 SATA HDDs require a RAID Controller! See section VIII internal Disk Array
Up to 4 LFF (3.5") hard disks can be configured into the base unit
With the HDD Extension Box Option B up to 6 LFF (3.5") hard disks can be configured, with Option C up to 8 HDDs.
The on board SATA Controller can be used with up to 4x 3.5" SATA HDDs (no additional controller required), BUT:
If a LTO backup drive is configured, then the 4 onboard SATA ports for HDDs are not available!
In this case for any HDD solution a PCI based 8port RAID controller is necessary!
For up to 4x 3.5" SAS HDDs without SAS Tape a Patsburg SAS RAID controller is available
For up to 4x 3,5" SAS HDDs in combination with a SAS tape or fr all other HDD configurations a 8port PCIcontroller is required
Mixed configurations with Eco SATA drives and SAS drives are not allowed
3.5" SAS drives and 3.5" BC SATA drives can be mixed, but not used in one logical RAID volume
Hot replace is only possible running RAID.
3.5" HDD Economy SATA (S26361-F3700-*) configurations with follow RAID SAS Ctrl not allowed
S26361-F33669-E1 RAID Ctrl SAS 6G 1GB (D3116)
S26361-F33669-E3 RAID Ctrl SAS 6G 1GB (D3116C
S26361-F3700-E250 S26361-F3700-E500
HD 250GB 7.2krpm 3.5" ECO HD 500GB 7.2krpm 3.5" ECO
7200rpm,<9.0 ms, 16MB Cache 7200rpm,<9.0 ms, 16MB Cache
SATA 6Gb/s Economy SATA 6Gb/s Economy
hot plug/hot replace tray
hot plug/hot replace tray
max. 4/6/8x per system max. 4/6/8x per system
S26361-F4005-E530 S26361-F4005-E545 S26361-F4005-E560
HD 300GB 15krpm 3.5" HD 450GB 15krpm 3.5"
15.000rpm,<4ms, 16MB Cache 15.000rpm,<4ms, 16MB Cache 15.000rpm,<4ms, 16MB Cache
SAS 6Gb/s SAS 6Gb/s SAS 6Gb/s
hot plug/hot replace tray
hot plug/hot replace tray
hot plug/hot replace tray
max. 4/6/8x per system max. 4/6/8x per system max. 4/6/8x per system
S26361-F5520-E530 S26361-F5520-E545 S26361-F5520-E560
HD 300GB 15krpm 2.5" HD 450GB 15krpm 2.5"
15.000rpm,<3ms, 64MB Cache 15.000rpm,<3ms, 64MB Cache 15.000rpm,<3ms, 64MB Cache
SAS 6Gb/s SAS 6Gb/s SAS 6Gb/s
3.5" hot plug/hot replace tray
3.5" hot plug/hot replace tray 3.5" hot plug/hot replace tray
max. 4/6/8x per system max. 4/6/8x per system max. 4/6/8x per system
S26361-F3670-E500 S26361-F3670-E100 S26361-F3670-E200 S26361-F3670-E300
HD 500GB 7.2krpm 3.5" HD 1000GB 7.2krpm 3.5"
7200rpm,<9.0 ms, 64MB Cache 7200rpm,<9.0 ms, 64MB Cache 7200rpm,<9.0 ms, 64MB Cache 7200rpm,<9.0 ms, 64MB Cache
BC SATA 6Gb/s BC SATA 6Gb/s
hot plug/hot replace tray
hot plug/hot replace tray
hot plug/hot replace tray hot plug/hot replace tray
max. 4/6/8x per system max. 4/6/8x per system max. 4/6/8x per system max. 4/6/8x per system
S26361-F3670-E400
HD 4TB 7.2krpm 3.5"
7200rpm,<9.0 ms, 64MB Cache
BC SATA 6Gb/s
hot plug/hot replace tray
max. 4/6/8x per system
S26361-F5241-E100 S26361-F5241-E200 S26361-F5241-E300 S26361-F5241-E400
HD 1TB 7.2krpm 3.5"
7200rpm,<9.0 ms, 32MB Cache 7200rpm,<9.0 ms, 32MB Cache 7200rpm,<9.0 ms, 32MB Cache 7200rpm,<9.0 ms, 32MB Cache
BC SAS 6Gb/s BC SAS 6Gb/s BC SAS 6Gb/s BC SAS 6Gb/s
hot plug/hot replace tray
hot plug/hot replace tray
hot plug/hot replace tray hot plug/hot replace tray
max. 4/6/8x per system max. 4/6/8x per system max. 4/6/8x per system max. 4/6/8x per system
K
Fujitsu PRIMERGY Server 15 of 24
