System configurator and order-information guide
PRIMERGY TX150 S8 Status 2016-02-29
K
2.5" HDDs for SFF base units; SAS or more than 4 SATA HDDs require a RAID Controller! See section VIII internal Disk Array
Up to 8 SFF (2.5") hard disks can be configured.
With the HDD Extension Box Option D up to 16 SFF (2.5") hard disks can be configured.
With the HDD extension box 2 hardware RAID controllers have to be ordered!
The On board SATA Controller can be used with up to 4x 2.5" SATA HDDs (no additional controller required)
If a SAS based backup is configured, then the 4 onboard SATA ports for HDDs are not available any more!
In this case for any HDD solution a PCI based 8port RAID controller is necessary!
For up to 4x 2.5" SAS HDDs with RAID 0/1 functionality a Patsburg Upgrade Kit is required (no SAS tape option)
Mixed configurations with Eco SATA drives and SAS drives are not allowed
2.5" SAS drives and 2.5" BC SATA drives can be mixed, but not used in one logical RAID volume
Hot replace is only possible running RAID.
Mixed configuration 2.5" BC-SATA/BC-SAS with SAS 10K (S26361-F4483-E130/E145/E160) drives not allowed.
2.5" SAS drives and 2.5" BC SATA drives can be mixed, but not used in one logical RAID volume
SFF (2.5") HDD-Box for additional
SAS SFF (2.5") Base Unit only
8x SFF (2.5") SAS hard disks
see Conf. diagram Option D
in the accessible bay area For the 8x 2.5" HD Extension Box
3.2 * 5.25", satin black bezel
2 PCI based modular RAID controller is necessary
max. 1x per system see Section VIII
S26361-F2826-E140 For a later configuration of more than 4 SATA HDDs, the trigger is not necessary
Trigger to request a PCI SAS Controller In this case it is sufficient to implement a SAS controller!
for configuring more than 4 SATA HDDs
It is not allowed to connect the SATA HDDs to different controllers
max. 1x per system In case of running more than 4 HDDs, all of them have
to be connected to the PCI based Controller
Fujitsu PRIMERGY Server 16 of 24
