TX2560 M2 / RX2560 M2
Operating Manual 61
Starting up and operation
6.2 Controls and indicators
6.2.1 Front of server
Figure 7: Front side connectors
1 2x USB 3.0 6 CSS indicator
2 Front VGA 7 Global Error indicator
3 Reset button 8 HDD/SSD activity indicator
4 NMI button 9 On/Off button / Power-on indicator
5 ID indicator/ID button 10 AC connected indicator
