TX2560 M2 / RX2560 M2
Operating Manual 69
Starting up and operation
4 LAN speed
indicator
(System LAN)
Steady yellow signal in the event of a LAN transfer rate
of 1 Gbit/s
Steady green signal in the event of a LAN transfer rate
of 100 Mbit/s.
Remains dark in the event of a LAN transfer rate of
10 Mbit/s.
5 CSS CSS indicator (orange)
– Lights up orange if a prefailure event was detected
for a CSS component that you can fix yourself (for
reasons of precaution) with the CSS concept.
– Flashes orange if an error was detected that you can
fix yourself with the CSS concept.
– Does not light up when the system is OK.
If the event is still acute after a power cycle, the indicator
is activated after the restart.
The indicator also lights up in standby mode.
For more information on the CSS concept, see
"Customer Self Service (CSS)" on page 13.
6ID
ID indicator (blue) on the system board, visible through
the chassis perforation.
Lights up blue when the system has been selected by
pressing the ID button. To deactivate, press the button
again.
The ID indicator can also be activated via the ServerView
Operations Manager and the iRMC S4 Web interface
and its status reported to the ServerView Operations
Manager and to the iRMC S4.
