Application Unit Application Unit AU47

U41861-J-Z126-1-76 13

Dokuschablonen 19x24 Version 7.4us für FrameMaker V7.x vom 09.02.2010 © cognitas GmbH 2001-2010

29. June 2015 Stand 16:47.07 Pfad: P:\FTS-BS\Server\SE-Server\SE-Doku\1303909_BA_Additional\prod_e\ba_addon.k03

2.1.1.2 Indicators on the operator control panel

ID ID indicator (blue)

Lights up blue when the

Application Unit has been selected by pressing the ID

button. To deactivate, press the button again.

The ID indicator can also be activated via the ServerView Operations Manager

and the iRMC Web interface, and the status is reported to the ServerView

Operations Manager and the iRMC.

Status indicator (green)

Does not light up when th

e Application Unit is switched off but is connected to

the power supply (power cable connected).

Lights up green during the power up delay and in normal system operation

(S0).

Status indicator (power cable connected)( green)

on the right-hand side of the On/Off switch

Does not light up in the following cases:

–

The Application Unit is not connected to the power source

–

The Application Unit Unit is switched on and operating normally (S0)

Lights up green when one of the following cases occurs:

–

The Application Unit is switched off but connected to the power supply

(power cable connected)

– The

Application Unit is switched on but is in the power up delay

I After the Application Unit has been connected to the power source, it

takes approximately 60 seconds until the Application Unit has entered

standby mode.

HDD activity indicator (green)

Lights up green when an internal hard disk drive or a solid state drive is being

accessed.
