4.1.2 Operating and indicator elements (rear)
You can see the status LEDs of the SAS I/O module and the status LEDs of the power
supply units on the rear side of the ETERNUS JX40 subsystem.
Status LEDs of the SAS expander unit
Figure 12: Status LEDs on the rear of the device
UNIT ID LED
Ready/Fault LED
Debug(EXP-TTY)
SAS-OUT(Widelink)
SAS-OUT
Link/Fault LED
SAS-IN
Link/Fault LED
SAS-IN(Widelink)
Status/Fault LED AC Inlet
Ejector levers of a power supply unit Ejector levers of a power supply unit
