ETERNUS JX40 disk storage system Periphery
30 U41861-J-Z126-1-76
v CAUTION!
The subsystem does not switch off automatically in the case of overheating in order
to allow the the connected server to be shut down properly. Overheating is reported
in the BS2000 console window and also results in a Remote Service call.
Status LEDs of the hard disk drives
Figure 11: Status LEDs of the hard disk drives
I Each of the 24 possible hard disk drives has a “Ready” LED and a “Fault/Identifi-
cation” LED.
LED Color Status Meaning
Ready LED Green On Normal operation
Off Not ready
Fault LED Yellow Off Normal operation
On/blinking Error detected, notify Customer Support
