Periphery ETERNUS LT40 S2 tape library

U41861-J-Z126-1-76 47

Dokuschablonen 19x24 Version 7.4us für FrameMaker V7.x vom 09.02.2010 © cognitas GmbH 2001-2010

29. June 2015 Stand 16:47.07 Pfad: P:\FTS-BS\Server\SE-Server\SE-Doku\1303909_BA_Additional\prod_e\ba_addon.k05

The tables below show the numbering of the slots (including the mailslots) when the

cartridges or their labels are viewed:

The command to open a mailslot may be denied if the robotics is busy with some operation.

In that case "Busy" is displayed. The command has to be repeated once the robotics

operation is finished..

You move cartridges from a slot or a drive to a mailslot and vice versa via OCP using the

menu Commands > Move Media.

Mailslot 3: cleaning cartridge

(used for auto cleaning

Slot 7 Slot 8 Slot 9

Mailslot 2: I/E port (BS2000) (drive 2

if present, otherwise unused)

Slot 4 Slot 5 Slot 6

Mailslot 1: I/E port (BS2000)

(drive 1)

Slot 1 Slot 2 Slot 3

Table 3: ETERNUS LT40 S2: Slot numbers of the left magazine with mailslots

Slot 21 Slot 20 Slot 19 Slot 18

Slot 17 Slot 16 Slot 15 Slot 14

Slot 13 Slot 12 Slot 11 Slot 10

Table 4: ETERNUS LT40 S2: Slot numbers of the right magazine
