Assigning appliance and device types
23
590-591-609D
Type a name in the New Name field. Names of target devices can be up to 15
characters long. Valid characters are A through Z, a through z, 0 through 9, space,
and hyphen.
Click OK to transfer the new name to the Names window. The selection is not
saved until you click OK in the Names window.
Repeat steps 1 to 3 for each target device in the switching system.
Click OK in the Names window to save the changes, or click X or press Escape
to
exit without saving changes.
If a KVM-IA has not been assigned a name, the EID is used as the default name. To list
target devices alphabetically by name, press Alt
+N or click Name in the Main window.
3.9.2 Assigning appliance and device types
The KVM s3-1621 appliance automatically discovers attached tiered appliances, but
you must specify the number of ports on the tiered appliances through the Devices
window. Fujitsu Technology Solutions console switches and other earlier appliance
models are listed in the Type category for the tiered appliances. When you select a
configurable appliance from the list, the Modify button becomes available, so you can
assign it the correct number of ports.
3.9.2.1 Accessing the Devices window
Press Print Screen to start the OSCAR interface. The Main window opens.
Click Setup - Devices. The Devices window opens.
Figure 10: Devices window
When the KVM s3-1621 appliance discovers a tiered appliance, the port numbering
changes to accommodate each target device under that appliance.
