Your docking cradle (optional)
As well as fast cha rging, your docking cradle is a device that also allows you to quickly connect
your Tablet PC to your peripherals such as a monitor, keyboard, mouse, etc. You only need
to dock the Tablet PC to be able to work with your peripheral devices.
Cradle components
PortsPortsCradle
1
3
2
4
9
5
6
7
8
1 = Dock release button
2 = Status LED
3 = Connector on the cradle for the docking
port of the Tablet PC
4=USB3.0port
5 = VGA monitor port
6 = HDMI port
7 = LAN port
8 = Security Lock device
9 = DC jack socket (DC IN)
ThestatusLED(2)ofthecradlelightsupassoonasitisconnected
to the pow er supply and the Tablet P C is connected to the powered
cradle, eve n if the Tablet PC is switched off.
TheLANportonthecradlesupportsWake-On-LANfortheSTYLISTICQ50(G3
only).
Two additional external monitors can be operated with theSTYLISTICQ50
eitheron the external monitor port (VGA) or on the HDMI port of the cradle.
Simultaneous operation of two external monitors is supported (see "Screen
resolutions
forintegratedscreenandexternalscreens",Page83).
