Accessories for your Tablet PC (opti

onal)

Adapter cable (optional)

3 adapter cables are available for your device:

• USB Ty pe-C to HDMI

•USBType-Ctomi

croHDMI

• Full-USB-to-LAN:

LAN Conversio

n Cable Kit: 1 x USB-to-LAN (GbE, limited performance)

For technical speci¿cations, see chapter"

Adapter cables (optional)", Page 86.
