Split system (Single phase and 3-phase type)
94 Maintenance Document 1544-1
6.1.4 MAIN PCB, FILTER PCB, and INDICATOR PCB removal
screws
Hook (2 places)
Remove the 1 mounting screw
Remove the INVERTER BOX COVER
by sliding upward.
DIODE BRIDGE
MAIN PCB
ACTPM
FILTER PCB
INDICATOR PCB
Single Phase type
