2.12 STEAM PRESSURE GAUGE (Fig. 5)
The steam pressure gauge assembly should be assembled in accordance with Fig. 5 using a
suitable sealant on all joints.
Screw the assembly into the top of the boiler and connect the copper tube from the control panel box to
the nipple provided on the assembly.
2 2
9
STEAM PRESSURE
GAUGE
STEAM COCK
SYPHON
FIG. 5 STEAM PRESSURE GAUGE
