GFSE-Std-0499
1
INTRODUCTION
SECTION 1
1.1 General (Fig. 1)
The Fulton Series E Gas Fired Steam Boiler is a vertical two pass boiler of simple and efficient design
and construction. Every care has been taken in the manufacture of the boiler to ensure that quality
and reliability standards are maintained. However, satisfactory performance can only be ensured if
the installation recommendations, operating routines and maintenance schedules laid out in this
manual are adhered to.
For Propane Boilers read Section 2.19 before proceeding.
1.2 Technical Data
BOILER MODEL
6E 8E 10E 15E 20E 30E 40E 50E 60E
Performance
lb/h (F & A 100
o
C) 210 280 350 525 700 1050 1400 1750 2100
kg/h (F & A 100
o
C) 96 128 160 240 320 480 640 800 960
Firing Rates
Approx. BTU input (000) 255 340 424 637 849 1273 1360 2121 2546
Natural Gas 1035 BTU
cu.ft./h 246 328 410 615 820 1230 1700 2050 2461
cu.m/h 7 9.3 11.6 17.4 23.2 34.8 46.4 58.1 69.6
Electrical Requirements
FLC (400V, 3ph, 50Hz) amps 4.7 4.7 4.7 4.7 4.9 4.9 6.9 6.9 8.6
FLC (230V, 1ph, 50Hz) amps 12.7 12.7 12.7 12.7 14.9 14.9 19.3 19.3 19.3
The full load current (flc) of the feed water pump motor can vary with the type and duty
requirements of the pump supplied. The figures quoted above are given as a guide only.
Miscellaneous
Water Content (Imp Gal) 13 15 20 33 64 141 204 204 223
Water Content (Litres) 59 68 91 150 291 640 927 927 1022
Approx. Net Weight (lb) 1540 1590 1785 2130 3135 4480 6728 6728 6944
Approx. Net Weight (kg) 700 720 810 965 1420 2030 3050 3050 3150
Nat. Gas Head
Pipe Size (in.) 1 1 1 1.25 1.25 1.5 2 2 2
Required Vertical 2060 2160 2210 2365 2440 2745 2845 2845 3000
Clearance (mm)
(Floor to Ceiling)
2
