FIG. 8 BOILER TOP COMPONENTS
Safety Valve
Flame Detector
Burner Assembly
Water Level
Probes
Ignition Electrodes
Steam Supply
Pipe
Flame Detector
Location
Oil Supply
Connections
Electrical
Connection Box
Ignition
Transformer
Oil Supply
Valves
Oil Pump
Adjustable
Air Control
Oil Supply
Ignition
Electrodes
Secondary Air
Damper
