J OIL-E-08 2008
1 10535 1 Valve, steam stop DN20 6 - 8
10536 1 Valve, steam stop DN25 10
10537 1 Valve, steam stop DN32 15
2 10566 1 Gauge, pressure 4in. x 250psi 6 - 15
3 SA0001 1 Gauge, pressure assy. 6 - 15
4 10565 2 Tee 6 - 15
5 10548 1 Valve 6 - 15
6 10655 1 Plug 6 - 15
7 10564 1 Syphon, pigtail 6 - 15
8 10001 1 Refractory, furnace Top 6 - 10
12037 1 Refractory, furnace Top 15
9 12040 1 Refractory, furnace Bottom 6 - 15
10 10006 1 Door, cleanout 6 - 15
11 10009 1 Handhole assembly Top 6 - 8
10010 1 Handhole assembly Top 10
10011 1 Handhole assembly Top 15
13764 2 Handhole assembly Bottom 6 - 15
12 10017 A/R Gasket, handhole 6 - 15
13 10023 1 Wrench, tee Handhole 6 - 15
14 11524 1 Valve, blowdown 6 - 15
15 14257 1 Valve, feed water stop 6 - 15
16 SA0002 1 Valve, check assembly 6 - 15
17 11824 2 Gasket 6 - 15
18 14126 1 Valve, check 6 - 15
19 11825 2 Flange 6 - 15
20 10119 1 Flue,ange 6-10
10120 1 Flue,ange 15
21 10417 1 Probe, water level 6 - 15
11882 1 Probe, water level 6 - 8
11774 1 Probe, water level 10 - 15
22 099E9360 2 Basket, probe 6 - 15
23 10558 2 Valve, steam safety 3/4in. Bir. 130psi 6 - 15
11504 1 Valve, steam safety 3/4in. N.V. 130psi 6 - 15
11609 2 Valve, steam safety 3/4in. Bir. 125psi 6 - 15
11952 1 Valve, steam safety 3/4in. Bir. 140psi 6 - 15
11953 1 Valve, steam safety 3/4in. Bir. 165psi 6 - 15
24 10135 A/R Gasket,uecover 6-15
25 10022 1 Brush,ue 6-15
26 13508 1 Connector,ue,male 6in. 6-10
13510 1 Connector,ue,male 8in. 15
13509 1 Connector,ue,female 6in. 6-10
13511 1 Connector,ue,female 8in. 15
27 13568 3 Clip,ueconnector 6-15
28 SA0045 1 Pipe, feed water dip 6 - 15
SA0046 1 Pipe, feed water dip for TDS systems 6 - 15
December 2004
A1-1-1 BOILER SHELL AND FITTINGS, 6 - 15
(UK and Australia)
Item Part Number Qty Description Remarks Size
Note:
To comply fully with safety regulations it is essential that the correct safety valves are used. If in any doubt
please contact Fulton Service Dept’ for assistance.
