FULTON 60J - Burner Assembly

J OIL-E-08 2008
Item Part Number Qty Description Remarks Size
1 SA0036 1 Burner assembly complete 20
SA0037 1 Burner assembly complete 30
2 10285 1 Adaptor, photocell 20 - 30
 3  10290    1  Sensor,ame              20-30
4 10595 1 Tube, photocell adaptor 20 - 30
5 10729 1 Connector 16mm 20 - 30
6 SA0011 1 Lead, ignition assembly 20 - 30
7 10249 2 Electrode, angle Rajah 20 - 30
8 10321 1 Cable, ignition 20 - 30
9 020EO330 1 Burner assembly 20
030EO330 1 Burner assembly 30
10 SA2209 1 Tube, blast was 10127 20 - 30
11 10144 A/R Rope, insulation 20 - 30
12 10253 2 Electrode, ignition 20 - 30
13 10259 1 Nozzle 5 g/h 20
10262 1 Nozzle 7 g/h 30
14 10256 1 Adaptor, single nozzle 20 - 30
15 10318 1 Spring, eye glass 20 - 30
16 10319 1 Glass, eye Pyrex 20 - 30
17 10325 7 Clip 1/2in. 20 - 30
18 10383 1 Plate, top 20 - 30
 19 SA0023    1  Deector        was10396    20-30
20 10581 1 Nipple, pipe 1/8in. x 12in. 20 - 30
21 10716 1 Elbow 20 - 30
22 10785 6 Bolt 1/4in. x 3/4in. UNC 20 - 30
23 10786 2 Bolt 6 x 16mm plated 20 - 30
24 10800 1 Nut M10 plated 20 - 30
25 SA0005 1 Gate, air 20 - 30
26 10810 2 Grubscrew 1/2in. x 1/4in. 20 - 30
27 10832 6 Nut 1/4in. UNC 20 - 30
28 10838 1 Nut, domed 10mm plated 20 - 30
29 10839 1 Lever, air damper 20 - 30
30 10849 2 Washer, spring 20 - 30
31 10977 2 Washer, eye glass 20 - 30
 32 11033    8  Washer,at               20-30
33 11139 6 Washer, spring 20 - 30
34 050EO430 1 Plate, burner 20 - 30
35 050EO470 1 Holder, electrode 20 - 30
36 10796 5 Bolt 20 - 30
37 10850 5 Washer, spring 20 - 30
38 10842 5 Washer 20 - 30
39 11131 1 Ring, combustion 20 - 30
December 2004
B2-2-1 BURNER ASSEMBLY, OIL, 20 - 30
