INSTALLATION
SECTION 2
2.1 GENERAL
The installation of a Series J Oil Fired Steam Boiler should be carried out by competent personnel in
accordance with all relevant safety regulations. It is the responsibility of the installer to ensure that these
regulations are complied with.
2.2 SITING
 Theboilerhouseshouldbesufcientlylargetoalloweasyandsafeaccesstoallpartsoftheboilerfor
installation, operation and maintenance purposes. Reference should be made to Section 5 - General
Data to ascertain the relevant dimensions and special note taken of the vertical clearance required for
the removal of the burner.
 Theooringmustbelevel,laidinanon-combustiblematerialandbeofsufcientstrengthtosupportthe
boiler.
2.3 VENTILATION
 Adequatefresh,cleanairisnecessaryforsafeandefcientcombustion,andshouldbeprovidedat
high and low level in accordance with IGE/UP/10 Edition 2. It is essential that only fresh air is allowed
to enter the combustion air system. Foreign substances, such as combustible and volatile materials in
the combustion system can create hazardous conditions.
Note:
(a) Ensure there is adequate ventilation in the boiler room. Lack of ventilation will create a high
temperature and cause control lockout.
(b) Do not keep exhaust fans running with windows, doors and vents closed, this will interfere with
the necessary boiler draught.
(c) Do not store chemicals such as perclorethylene in the boiler house, the fumes may damage the
  boilerandueandcausetheburnertolockoutonamefailure.
Ventilation requirements
Boiler Model 6J 8J 10J 15J 20J 30J 40K 50J 60J
High Level (cm
2
) 305 360 420 560 700 980 1260 1540 1820
Low Level (cm
2
) 610 720 835 1115 1395 1960 2520 3085 3645
