3.3 INDICATOR LIGHTS
 Indicatorlightsarettedtothecontrolpanelasanadditionalaidtotheoperator.
The meaning and operating sequence of these lights is as follows:
Start / Low Water Reset
This switch is used to start the boiler and to reset the low water alarm. When the switch is pressed
to initiate the start-up sequence, the low water alarm lamp also illuminates and the low water
audible alarm sounds. Keeping the switch depressed for approximately 2 seconds cancels the low
water alarm and initiates the burner start sequence.
Illumination of this switch and sounding of the audible alarm at any other time other than at switch
on indicates that the boiler has gone to a lockout (safe condition) due to low water. Once the water
in the boiler has been restored to a safe operating level, pressing the switch will reset the controls.
Circuit On
Indicates that power is being supplied to the control panel.
Low Water Alarm (1st. low water).
This light will energise, when the boiler is switched on and the water level is between 1st. low
water and 2nd. low water. A light will illuminate and a pulsing alarm sound.
Low Water Reset (2nd low water).
The 1st. low water light and alarm are replaced by the 2nd. low water light and a continuous
alarm, indicated by the low water reset switch.
  Thesecondalarmmustbereset,therstalarmwillbeautomaticallyresetbythereturnto 
normal water level.
Ignition
This lamp indicates the ignition transformer has been energised, it will remain illuminated for
5 - 10 seconds approximately during the ignition sequence.
Burner On
  Thislampindicatesthattheburnerisrunningandthattheameisbeingmonitoredbythe
burner programmer.
Flame Failure Alarm (reset)
  Thisswitchwillilluminateiftheburnergoestoalockoutconditionduetoamefailure.
Pressing the switch will reset the burner controller.
WARNING
No more than two attempts should be made to start the boiler by resetting the
ame failure alarm (reset) Further attempts could cause the boiler and ue
system to ll with vaporized oil which could cause an explosion.
Oil Valve
The two lamps provide a visual indication that the magnetic oil valves have been energised.
Low Flame / Start and Main Flame.
  Models40Jand60Jarettedwiththefollowingindicatorlampsinplaceofthetwooilvalve
indicator lamps:
  Theburnersonmodels40Jand60Jarettedwithatwo-stagecombustionsystem.Thelow
  amestartlampindicatesthattherststageofcombustionisinprogressandthattheburner
  shouldbering.Oncethesecondstageofcombustionisreached(fullringposition),thelow
  amestartlampextinguishesandthemainamelampilluminates.
This lamp will remain illuminated until the burner is shut down.
