WARNING
It is the responsibility of the installer to ensure all parts supplied
with the boiler are tted to the boiler in a correct and safe manner.
5
Connection Sizes (DN) (F=female, M=male) All connections BSP
Model 6/8 10 15 20 30 40 50 60
1. Steam Outlet 20F 25F 32F 32F 40F 50F 50F 50F
2. Feed Water 15M 15M 15M 15M 15M 15M 15M 15M
3. Safety Valve (discharge) 20F 20F 20F 20F 20F 32F 32F 32F
4. Oil Pump (inlet/return) 10M 10M 10M 10M 10M 10M 10M 10M
5. Main Boiler Blowdown 20F 20F 20F 25F 25F 25F 25F 25F
6. Water Column Blowdown 20F 20F 20F 20F 20F 20F 20F 20F
7. Sight Glass Blowdown 8F 8F 8F 8F 8F 8F 8F 8F
8. Flue Outlet (dia. mm) 152 152 203 254 305 305 305 305
Specication
Model 6/8 10 15 20 30 40 50 60
Output (kg/h, F&A 100
O
C) 96/128 160 240 320 480 640 800 960
Standard Working
Pressure (bar) 10.34 10.34 10.34 10.34 10.34 10.34 10.34 10.34
Firing Rates
Input (kW/h) 75/100 124 187 250 373 501 622 746
Input (BTU/h x 1000) 255/340 425 637 849 1273 1712 2122 2547
Input 35 sec. oil (US gal/h) 1.9/2.5 3.1 4.7 6.2 9.3 12.4 15.5 18.6
Input 35 sec. oil (litre/h) 7.0/9.4 11.4 17.6 23.5 35.3 47.0 58.7 70.5
Nozzle Size (US gal/h) 1.65/2.0 2.25 3.5 5.0 7.0 2 x 5.0 1 x 7.0 2 x 7.0
Nozzle Spray Angle 80
O
/S 80
O
/S 80
O
/S 80
O
/SS 80
O
/SS 80
O
/SS 1 x 5.0 80
O
/SS
80
O
/SS
Oil Pressure (barg) 8.8/10.6 13.1 12.1 10.6 12.1 10.6 16.6 12.1
Oil Pressure (psig) 127/153 189 176 154 176 154 240 176
Capacities and Weight
Water Content (litre) 90 90 205 290 640 1020 1020 1020
Weight Empty (kg) 810 810 1190 1420 2030 3150 3150 3150
Weight Operating (kg) 900 900 1395 1710 2670 4170 4170 4170
Electrical Requirements
FLC @ (Amp)
400V 3ph 50Hz 4.7 4.7 4.7 4.9 4.9 6.9 6.9 8.6
240V 1ph 50Hz 12.7 12.7 12.7 14.9 14.9 19.3 19.3 19.3
Oil Boiler Combustion Values
CO
2
range 11.5 - 12.5%
CO less than 100ppm
O
2
range 5 - 4%
Excess air 30 - 20%
Smoke 3 max.
