J OIL-E-08 2008
A1-2-1 BOILER SHELL AND FITTINGS, 20 - 60
(UK and Australia)
Item Part Number Qty Description Remarks Size
1 10537 1 Valve, steam stop DN32 20
10538 1 Valve, steam stop DN40 30
10539 1 Valve, steam stop DN50 40 - 60
2 SA0044 1 Valve, check assembly 20 - 60
3 11825 2 Flange 20 - 60
4 11824 2 Gasket 20 - 60
5 14126 1 Valve, check 20 - 60
6 14257 1 Valve, feed water stop 20 - 60
7 SA0045 1 Pipe, feed water dip 20 - 60
SA0046 1 Pipe, feed water dip for TDS systems 20 - 60
8 13732 1 Brush,ue 20-60
9 10006 1 Door, cleanout 20 - 60
10 13764 2 Handhole assembly Bottom 20 - 60
10012 1 Handhole assembly Top 20
10013 1 Handhole assembly Top 30
10014 1 Handhole assembly Top 40 - 60
11 10017 A/R Gasket, handhole 20 - 30
10018 A/R Gasket, handhole 40 - 60
12 11525 1 Valve, blowdown 20 - 60
13 13512 1 Connector,ue 10in. 20
13514 1 Connector,ue 12in. 30-60
14 13568 3 Clip, connector 20 - 60
15 13544 1 Plate,uecover 20
13545 1 Plate,uecover 30
13546 1 Plate,uecover 40-60
16 10136 Roll Gasket,uecoverplate 20-60
17 10023 1 Wrench, tee 20 - 60
18 11952 1 Valve, steam safety 3/4in. 140psi Birket 20 - 30
11953 1 Valve, steam safety 3/4in. 165psi Birkett 40 - 60
19 SA2200 1 Basket, probe 20 - 60
20 10417 1 Probe, water level 20 - 60
11774 1 Probe, water level 20 - 60
21 SA0001 1 Gauge, pressure assy. 20 - 60
22 10565 2 Tee 20 - 60
23 10655 1 Plug 20 - 60
24 10548 1 Valve 20 - 60
25 10564 1 Syphon, pigtail 20 - 60
26 10566 1 Gauge, pressure 4in. x 250psi 20 - 30
27 10002 1 Refractory, furnace Top 20
12038 1 Refractory, furnace Top 30
12149 1 Refractory, furnace Top 40
12039 1 Refractory, furnace Top 50 - 60
28 12041 1 Refractory, furnace Bottom 20 - 30
12148 1 Refractory, furnace Bottom 40
10003 1 Refractory, furnace Bottom 50 - 60
December 2004
Note:
To comply fully with safety regulations it is essential that the correct safety valves are used.
If in any doubt please contact Fulton Service Dept’ for assistance.
